Compact Design: Built on a JAC light-duty chassis, this truck easily navigates narrow streets and residential alleys.
High Compression Ratio: The advanced hydraulic system ensures efficient waste compression, maximizing the 3-ton loading capacity.
National VI Compliance: Meets strict emission standards, ensuring eco-friendly operation in city centers.
Durable Construction: The body is made of Q345 high-strength manganese steel for long service life.
Model: JAC Shuailing / Junling (Light Duty)
Drive Type: 4×2
Engine Power: 115 HP / 130 HP (Diesel)
Emission Standard: National VI (Euro 6 equivalent)
Tire: 7.00R16 Steel Wire Tire
Cab: Single row, comfortable interior with A/C
Upper Body Specifications
Body Volume: 4 CBM / 5 CBM (Standard for 3-Ton load)
Material: High-quality Carbon Steel Q345
Loading Type: Rear hanging bucket (fits 120L/240L bins)
Control System: CAN Bus / PLC Electronic Control
Hydraulic System: Famous brand cylinders and multi-way valves
Painting: Anti-corrosion paint
Product Name: JAC 3-Ton Compactor Garbage Truck
Chassis Brand: JAC (Jianghuai Automobile)
Drive Type: 4×2 Left Hand Drive
Engine: Anhui Cummins / Yunnei Power (Diesel)
Horsepower: 115 HP / 130 HP
Emission Standard: National VI (Equivalent to Euro 6)
Transmission: 5-Speed Manual Gearbox
Tire Specification: 7.00R16 Steel Wire Tires
Braking System: Air Brake with ABS
Wheelbase: 2850 mm / 3308 mm
Upper Body System Parameters
Body Capacity: 4 CBM / 5 CBM (Standard for 3-Ton Payload)
Body Material: Q345 High-strength Manganese Steel
Compression Ratio: 1:2.5 to 1:3
Sewage Tank: Large capacity tank with discharge valve to prevent leakage
Control System: CAN Bus Electric Control + Manual Lever (Dual System)
Loading Mechanism: Rear hanging bucket lifter (Suitable for 120L/240L plastic bins)
Painting: Anti-corrosion primer + Finish paint
Hydraulic Cylinder: Famous Brand (Stable and Durable)
Solution for Narrow Urban Streets
The JAC 3-Ton Compactor Garbage Truck is specifically designed for high-density urban areas. Due to its “Blue Plate” size (compact dimensions), it can freely enter underground parking lots, narrow residential alleys, and old city streets where larger heavy-duty trucks cannot access. It serves as an essential “capillary” vessel in the city waste collection network.
High Efficiency for Communities and Schools
This JAC garbage truck is widely used in residential communities, universities, factory zones, and parks. Compared to traditional open dump trucks, its compression technology allows it to carry 2-3 times more waste per trip. This significantly reduces transportation costs and improves work efficiency for sanitation companies.
Environmental Friendly & Hygiene
Meeting the National VI emission standards, this truck is environmentally friendly with low noise and low exhaust output. The key feature is its fully sealed body design. During the compression and transportation process, sewage flows directly into the dedicated sewage tank, ensuring.
Easy Operation
The vehicle is equipped with a dual control system (inside the cab and at the rear of the truck). The automated rear lifting mechanism can easily lift and dump standard 120L and 240L trash bins, reducing the physical labor required by sanitation workers.
